Cleaning Procedure of Air cooler



Hand spray Cleaning:-

By Hand spray, apply concentrate RXSOL-16-1049-020 ( Air Cooler Cleaner ) all over the cooler coils. for good emulsification & penetration. Allow the RXSOL-16-1049-020 for a minimum of 1 hour, then use a high pressure water to wash off the loosened deposits. During process always keep drain valve open. After satisfactory cleaning, and flushing through with fresh water, close air cooler drains.Note that during this process the engine must be stopped.



Soak method :

Machine parts with stubborn carbon deposits to be cleaned is dipped into conc. Soln.of ACC then allow deposits too. Be broken down and loosened before removal, then rinse.



3 to 5 litres of cleaning solution per square meter or as table below:



Engine HP. Solution of 10 to 25% RXSOL-16-1049-020 ( Air Cooler Cleaner )

6,000 to 12,000 2 to 3 litre

12,000 to 24,000 4 to 5 litre

24,000 or  more 6 litre

NOTE :

For cleaning of Air cooler and Air side of  turbochargers, a  solution  of  5 - 25% RXSOL-16-0009-ACC in fresh  water is recommended. Inject the solution for 10-15minutes, then similar quantity of fresh water injected to rinse off emulsifieddeposits.



Characteristics:

Formulated to remove oil, grease & carbon deposits from air coolers & scavenging system

Efficient and economical.

May be used for in-service cleaning.

Renders surfaces oil-repellent.

Maintains and stabilizes air cooler efficiency at a maximum.

Saves time, maintenance costs and avoids risks of damage when dismantling.

Leaves no residue and has no harmful effect on the engine.

Product in water solution is non-flammable, non-explosive and has no flash point.

Can be used for light carbon removal from machinery parts

        **Read the Material Safety Data Sheet before using this product**
