Oil Soluble Plugging Drilling Fluid
Part No. RXSOL-81-8201-025
is a superior plugging agent used to bridge and seal permeable formations in oil base mud systems.
Key details
| Part number | RXSOL-81-8201-025 |
|---|---|
| Standard packing | 25.00 Kg.PWD |
| Supply locations | Oil Soluble Plugging Drilling Fluid manufacturer supplier distributor in Mumbai, Kandla, Kolkata, Vizag, Chennai, India, Fujairah, Dubai, Sharjah, UAE, Gulf, Middle East, Muscat Oman, Kenya Africa. Get the best quality of Oil Soluble Plugging Drilling Fluid at a competitive price from us. We have ready stock of Oil Soluble Plugging Drilling Fluid in India, UAE Gulf, Oman, Kenya Africa. Contact us for bulk as well as small orders. |
Need this product at your port or plant?
Enquire Now<p style="text-align: justify;">
RXSOL Oil Soluble Plugging which can be used for leakage control by plugging in drilling, completion and workover, especially in sandstone formation of high permeability. The grain size and softening point can be selected in the period of manufacturing according to the formation pore and temperature. Generally is added into the killing fluid to play a role of anti-leakage. </p>
<ul>
<li>
RXSOL Oil Soluble Plugging is a superior bridging agent, field-proven to be highly effective when drilling high-permeability/ high-porosity zones with high differential pressures. Each grind size has a specially selected particle size distribution optimized to seal a wide range of formations.<br />
</li>
<li style="text-align: justify;">
RXSOL Oil Soluble Plugging is designed to bridge and seal permeable formations, reducing the possibility of stuck pipe, controlling lost circulation and providing filtration control. It is compatible with water-, oil- and synthetic-base mud systems.</li>
</ul>
<ul>
<li style="text-align: justify;">
The recommended treatment is 14 to 29 kg/m3 to reduce differential sticking tendencies. After initial treatment, periodic treatments should be used to maintain the desired concentration. Significant quantities of the medium and coarse grades will be removed by fine- mesh shale shaker screens (100 mesh or finer).<br />
</li>
<li style="text-align: justify;">
Fine-grade RXSOL Oil Soluble Plugging fiber is recommended for most applications due to its special particle size distribution. Very high-permeability formations, such as fractured carbonates and conglomerate zones, can require the medium or coarse products.<br />
</li>
<li style="text-align: justify;">
For see page losses, normal treatments are from 10 to 20 lb/bbl (29 to 57 kg/m3). Concentrations in the 20 to 35 lb/bbl (57 to 100 kg/m3) range are recommended for more severe lost circulation. Pilot testing is recommended before adding high concentrations because the material absorbs a small quantity of liquid when added to the mud system.<br />
</li>
<li style="text-align: justify;">
RXSOL Oil Soluble Plugging should be added to the mud system through a mixing hopper into a pit with good agitation, such as the suction pit. It is a one-sack product and does not require any additional additives. It is most effective when maintained at the desired concentration throughout the circulating system. However, treatment methods such as frequent periodic additions, sweeps, batch- or slug-treatments and pills have all been used successfully.<br />
</li>
<li style="text-align: justify;">
RXSOL Oil Soluble Plugging is compatible with all mud systems and can be used in combination with other lost-circulation materials, including Nut Plug, mica, sized calcium carbonate, gilsonite, etc.</li>
</ul>
<p>
Physical Properties :</p>
<table border="1" cellpadding="1" cellspacing="1" style="height: 144px; width: 762px;">
<tbody>
<tr>
<td>
GrindSize</td>
<td style="text-align: center;">
Fine </td>
<td style="text-align: center;">
Medium </td>
<td style="text-align: center;">
Coarse</td>
</tr>
<tr>
<td>
Finer than 8 mesh</td>
<td style="text-align: center;">
-----</td>
<td style="text-align: center;">
-------</td>
<td style="text-align: center;">
>95%</td>
</tr>
<tr>
<td>
Finer than 50 mesh</td>
<td style="text-align: center;">
> 80%</td>
<td style="text-align: center;">
</td>
<td>
</td>
</tr>
<tr>
<td>
Finer than 100 mesh</td>
<td style="text-align: center;">
> 90% </td>
<td style="text-align: center;">
< 60% </td>
<td style="text-align: center;">
< 15%</td>
</tr>
<tr>
<td>
Median (microns) </td>
<td style="text-align: center;">
44-74</td>
<td style="text-align: center;">
104-149</td>
<td style="text-align: center;">
420-840<br />
</td>
</tr>
</tbody>
</table>
<p>
<strong>Advantages</strong></p>
<ul>
<li>
Effective bridging and sealing agent for a wide range of formations|<br />
</li>
<li>
Offers unique particle sizes smaller than conventional lost-circulation materials yet larger than the solids found in most mud systems • Available in fine (original), medium and coarse grades, allowing the most appropriate particle sizes to be used .<br />
</li>
<li>
Inert material with minimum effect on mud properties.<br />
</li>
<li>
One-sack product with no other additive requirements.<br />
</li>
<li>
Compatible with all mud systems and other lost-circulation materials.<br />
</li>
<li>
Easily mixed and dispersed into the mud system.<br />
</li>
<li>
Easily passes through most shaker screens</li>
</ul>
<p>
<strong>Limitations</strong></p>
<ul>
<li style="text-align: justify;">
Can be removed from the circulating system by shale shakers and solids-control equipment, especially when using the medium and coarse grades with fine-mesh screens (<100 mesh), which requires close monitoring of shale shakers.<br />
</li>
<li style="text-align: justify;">
Biodegradable and can be subject to bacterial degradation. If fermentation is indicated, a biocide should be used at the recommended maximum treatment level.<br />
</li>
<li style="text-align: justify;">
Absorbs a small quantity of liquid when added to a mud system and can elevate flow properties when used at very high concentrations.<br />
</li>
<li style="text-align: justify;">
Treatments with additional wetting agent may be required in low stability or lightly treated oil-base muds because of the high surface area of this slightly absorbing material</li>
</ul>
<p>
<strong>Toxicity and Handling</strong></p>
<p>
Bioassay information is available upon request.</p>
<p>
Handle as an industrial chemical, wearing protective equipment and observing the precautions described in the Material Safety Data Sheet (MSDS).</p>
<p>
Dust can form an explosive mixture in the air. Keep away from open flames or other sources of ignition.</p>
<p>
Packaging and Storage</p>
<p>
RXSOL Oil Soluble Plugging fiber is packaged in 25 Kg, multi-wall, paper sacks).</p>
<p>
Store in a dry, well-ventilated area. Keep container closed. Store away from incompatibles. Follow safe warehousing practices regarding palletizing, banding, shrink-wrapping and/or stacking.</p>
